Omnigrad S TSC281

Product picture of: Omnigrad S TSC281

This product is no longer available.

Please check new generation in the section predecessor / successor or contact your local Endress+Hauser entity.

Features and specifications



  • Measuring principle


  • Characteristic / Application

    Bulk chemical and oil & gas industry

  • Thermowell / protection tube

    To be ordered separately

  • Insert / probe

    M.I. cable replaceable

  • Process connection

    Thread to thermowell: G1/2"

  • Operating temperature range

    K: -40...1100°C
    J: -40...750°C

  • Max. process pressure (static)

    Depends on thermowell

  • Accuracy

    Class 1 or 2

  • Response time

    t50 = 0.8 s
    t90 = 2 s

  • Integration head transmitter

    PCP 4...20 mA, HART, PROFIBUS-PA

Documents / Manuals / Software

  • Successor
